Designing a Fitted Wardrobe for Small Bedrooms

Measure the Room Before You Measure the Wardrobe

Before you think about doors or shelves, spend twenty minutes with a tape measure and a pencil. Note the usable width between walls, the ceiling height, and anything that will get in the way — radiators, sockets, light switches, skirting boards, and the swing of the bedroom door. In a small bedroom, a 100mm error can mean the difference between a wardrobe that fits and one that has to be rebuilt.

Pay particular attention to the corners. Very few rooms are truly square, and an alcove that measures 1,800mm at the top might be 1,760mm at the skirting. Take readings at three heights — floor, waist, and head height — and work to the smallest figure. If you are fitting between two walls, allow a 10mm scribe gap on each side so you can trim the end panels to the shape of the wall.

Sliding Doors Earn Their Keep in Tight Spaces

Hinged doors need roughly 600mm of clear arc to open properly. In a bedroom where the bed sits close to the wardrobe or the door swings into the same corner, that arc becomes a daily obstacle. Sliding doors run along a track and need no clearance in front of them at all, which is why they are usually the right choice for a small room.

There are two main systems. Top-hung tracks carry the weight of the doors from a header fixed to the wall or ceiling, leaving the floor completely clear and the running action smooth. Bottom-rolling tracks are cheaper and simpler to fit, but the track sits on the floor and gathers dust and grit, which eventually makes the doors drag.

Each door needs to overlap its neighbour by about 50mm so you cannot see through the gap between them. That means two doors covering a 1,200mm opening need to be roughly 650mm wide each. Allow around 100mm of depth for the track and door assembly when you plan the internal layout.

Work Out Hanging Heights Before Anything Else

Hanging space is the backbone of any wardrobe, and in a small bedroom it is the part you cannot afford to get wrong. Two heights matter.

• Long hanging — 1,500mm to 1,700mm of clear rail height for coats, dresses, and long garments. Plan for 1,700mm if you want to be safe.
• Short hanging — 1,000mm of clear height for shirts, blouses, and jackets. Double this up: two short rails stacked in a 2,100mm tall space gives you twice the hanging capacity of a single tall rail.

Leave at least 100mm between the top of the rail and the underside of the shelf above, so hangers can be lifted on and off without a fight. A rail positioned too close to a shelf is one of the most common complaints about fitted wardrobes, and it is entirely avoidable at the planning stage.

Shelving, Drawers, and the Space You Actually Use

Drawer position matters more than drawer size. Put drawers at waist height or below, where you can see into them and reach the back. Drawers above eye level are awkward and rarely used, so reserve the upper zone for shelves holding boxes, spare bedding, or items you only reach for occasionally.

• Shallow — 150mm deep for jewellery, socks, and underwear.
• Medium — 200mm for folded shirts and knitwear.
• Deep — 300mm for bedding, towels, and bulky items.

Allow at least 500mm of clear depth for drawer boxes to run in and out. If the carcass is 600mm deep and the door slides across the front, the drawer front has to clear the door thickness and the track — usually around 80mm. That leaves roughly 520mm of usable depth, which is plenty, but only if you account for it before cutting anything.

Choose Materials That Suit a Small Room

For the carcass, 18mm melamine-faced chipboard is the workhorse of fitted furniture. It is stable, wipes clean, and takes shelf pins and cam fittings well. If you plan to paint the wardrobe to match the walls, MDF gives a smoother finish and takes a primer more evenly. Solid timber is best kept for rails, trims, and any exposed edge you want to look sharp.

Light colours and matt finishes reflect light and make a small room feel larger. Gloss can work, but it shows every fingerprint and every ripple in the panel. If the wardrobe spans a full wall, consider making the door fronts match the wall colour so the unit recedes rather than dominates.

Fitting and Finishing

Order your carcass panels cut to size where you can, and have the door fronts machined with the hinge or roller cut-outs already done. Dry-fit the frame before you fix anything permanently, checking for level at the top and plumb at the sides. Pack the base up with adjustable feet or timber shims rather than trimming panels to suit a sloping floor.

Fix the top track or header into wall studs or a solid lintel wherever possible, not just into plasterboard. A loaded sliding door is heavy, and a track that sags after six months is a miserable thing to live with. Finish by scribing the end panels to the walls, fitting the doors, and adjusting the rollers until the gap between them is even from top to bottom. Done properly, a fitted wardrobe in a small bedroom should feel like part of the room — not something squeezed into it.
